MHD N54 Monitor License

Monitor your engine behavior to make sure it is running perfectly using a configurable and very responsive gauge layout with up to 8 fully adjustable gauges. 50+ engine parameters are available at a glance and are logged in the background! Activate the logging mode to save the data to a standard CSV file for later analysis using the built in log viewer. Additionally, we will happily provide free logs analysis.

These are some of the available monitors: Boost, Boost Target, Lambda (AFR), Intake Air Temp (IAT), Ignition Timing per Cylinder, Coolant Temperature, Oil Temperature, Oil Pressure, Transmission Temperature, High Pressure Fuel Pump (HPFP), Throttle Position, Wastegate Duty-Cycle (WGDC), RPM, Speed, EGT etc.


    Advanced parameters that are not exposed by BMW are available for fine monitoring and tuning (depending on the DME software version if MHD is not flashed) like Timing Corrections per Cylinder, Boost setpoint, Active torque limiter etc.




    MHD OTS Maps by Wedge Performance

    Stock

    306HP-340HP

    Stage 1 Maps

    Eight maps included Stage 1 and Stage 1+ FMIC (upgraded FMIC recommended). Each with 4 octane Variants (US OCT ACN91, 91, 93, 95 / RON 93, 95, 98, 102) using a peak of 15 to 17 PSI tapering to 10-12 PSI at redline.

    Stage 1

    up to 360HP / 520NM

    Stage 1+

    up to 390HP / 600NM

    Stage 2 Maps

    Eight maps included Stage 2 (High-Flow Downpipes) and Stage 2+ FMIC(DPs and upgraded FMIC recommended). Each with 4 octane Variants (US OCT ACN91, 91, 93, 95 / RON 93, 95, 98, 102) using a peak of 16 to 18 PSI tapering to 12-14 PSI at redline.

    Stage 2

    up to 380HP / 560NM

    Stage 2+

    up to 420HP / 650NM

    E85 mix maps

    For Ethanol blends of 25-60% targeting peak 18PSI to 14PSI (High-Flow Downpipes and upgraded FMIC + upgraded Low Pressure Fuel Pump for E40 and E60 recommended).

    up to 440HP / 670NM


    Supported Vehicles

    2006 - 2010
    135i, 335i/x and 535i/x

    2011 - 2013
    335is

    2009 - 2015
    Z4 35i/is

    2011 - 2012
    1M

    2008 - 2010
    X6 35i
